specifications of aluminum alloy 3003 aluminum sheet plate
among leading aluminum alloy manufacturers and suppliers in china, haomei aluminum offers 3003 aluminum sheet, aluminum plate and aluminum tread plate by the iso standard 6361 and the astm standards b209, b210, b211, b221, b483, b491, and b547. the 3003 h14, h16 and h18 are commonly used ones, and other tempers are available as well. haomei aluminum can produce 3003 of ultra width and thickness. the widest is 2650mm, and the thickest is 500mm. the internal stress is eliminated, which guarantees that there will be no deformation in the cutting process.
| alloy no. | si | fe | cu | mn | mg | cr | zn | ti | others | al |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | 0 | 0 | 0.10 | 0 | 0.20 | remain |
| aluminum alloy 3003 products | |||||
| products | type | temper | thickness(mm) | width(mm) | length（mm） |
| 3003 aluminum sheet | painted,bare,mill finish tread plate | o,h14, h16,h18, h19,h22, h24,h26,h28,h112 | 0.2-4.5 | 100-2600 | 500-16000 |
| 3003 aluminum coil | 0.02-0.055 | 100-1600 | coil | ||
| 3003 aluminum tread plate | 0.8-7.0 | 100-2600 | 500-16000 | ||
| 3003 aluminum plate | mill finish | 4.5-500 | 200-2650 | 500-16000 | |
features and applications of aluminum alloy 3003 aluminum sheet plate
3003 aluminum sheet plate contains about 1 to 1.5 percent manganese, and thus boasts excellent corrosion resistance. formed by either conventional cold working or hot working, 3003 is approximately 20% stronger than 1100 aluminum alloy. with good forming ability, excellent corrosion resistance and extraordinary welding property, 3003 aluminum sheet plate is usually applied as a raw material for light automobile battery shells, cookware, food containers, vehicle tanks, pressure containers and pipes etc.
ypical use of ultra-wide 3003 aluminum plate: bus skins, silos, antenna pot materials, wide curtain wall panels, wide roof panels etc.;
hot-rolled 3003 aluminum plate typical use: power battery casings, automobile heat shields, fuel tanks, water tanks, automobile skid plates, battery explosion-proof valves, battery covers, automobile interiors, nameplates, cans, medical devices, etc.;
3003 aluminum foil coil use: aluminum foil for honeycomb core products, electronic foils, honeycomb materials, lunch box materials, container foils etc.
strength of haomei aluminum
technologies: top polishing technology guarantees good luster and smooth surface.
markets: covering over 70 countries all over the world.
equipment: latest cutting lines providing a wide range of specifications.
production capacity: 400, 000 tons of annual yield.
service: over 30 people offering one-step service (marketing unit, sales unit and document unit) for overseas customers.
packaging and shipping
standard export packing with wooden cases or wooden pallets as required by clients. aluminum sheet, plate and coil products are wrapped by plastic films and brown papers. there are two kinds of packaging, which is eye to wall or eye to sky. generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
